com.gentics.cr.portlet.imagestore
Class GenticsImageStoreServlet

java.lang.Object
  javax.servlet.GenericServlet
      javax.servlet.http.HttpServlet
          com.gentics.cr.portlet.imagestore.GenticsImageStoreServlet

All Implemented Interfaces:

Serializable, javax.servlet.Servlet, javax.servlet.ServletConfig

public class GenticsImageStoreServlet
extends javax.servlet.http.HttpServlet

Servlet for resizing images for Content.Node

See Also:

Serialized Form

Field Summary

static int	BUFFER_SIZE buffer size for writing the image to the response
protected com.gentics.lib.log.NodeLogger	logger logger
private String	portalBasePath Portal basepath
private String	portalBasePathRegEx Regex that will be used to determine the portal basepath
private com.gentics.api.imagestore.RequestDecorator	requestDecoratorClass Will be instantiated with a class given by an optional servlet parameter which enables the user to modify header information and data in requests to the GenticsImageStore May be null.
private String	secret Configured secret for resize validation
private static long	serialVersionUID serial version uid
private com.gentics.api.imagestore.ImageUriMapper	uriMapper Will be instantiated with a class given by an optional servlet parameter which enables the user to customize exactly how requests to images are mapped to the actual location where the image will be fetched from.
private URI	urlPrefix The GenticsImageStore by default fetches the subject image from the host of the request (usually identical to the host the GenticsImageStore runs on).

Constructor Summary

GenticsImageStoreServlet()

Method Summary

protected void	doGet(javax.servlet.http.HttpServletRequest request, javax.servlet.http.HttpServletResponse response)
protected void	doPost(javax.servlet.http.HttpServletRequest request, javax.servlet.http.HttpServletResponse response)
protected void	doResizing(String mode, String width, String height, boolean cropandresize, String topleftx, String toplefty, String cropwidth, String cropheight, javax.servlet.http.HttpServletRequest request, javax.servlet.http.HttpServletResponse response, String imagePath) Do the resizing of an image and return the image
void	init()
private URI	toImageUri(javax.servlet.http.HttpServletRequest request, String imagePath) Gets the absolute URI for a relative image path.
protected void	writeImageToResponse(com.gentics.api.lib.upload.FileInformation image, javax.servlet.http.HttpServletResponse response) Write the image into the servlet response

Methods inherited from class javax.servlet.http.HttpServlet

doDelete, doHead, doOptions, doPut, doTrace, getLastModified, service, service

Methods inherited from class javax.servlet.GenericServlet

destroy, getInitParameter, getInitParameterNames, getServletConfig, getServletContext, getServletInfo, getServletName, init, log, log

Methods inherited from class java.lang.Object

clone, equals, finalize, getClass, hashCode, notify, notifyAll, toString, wait, wait, wait

Field Detail

serialVersionUID

private static final long serialVersionUID

serial version uid

See Also:

Constant Field Values

BUFFER_SIZE

public static final int BUFFER_SIZE

buffer size for writing the image to the response

See Also:

Constant Field Values

portalBasePath

private String portalBasePath

Portal basepath

portalBasePathRegEx

private String portalBasePathRegEx

Regex that will be used to determine the portal basepath

logger

protected com.gentics.lib.log.NodeLogger logger

logger

urlPrefix

private volatile URI urlPrefix

The GenticsImageStore by default fetches the subject image from the host of the request (usually identical to the host the GenticsImageStore runs on). However, in some network constellations the host name used to make the request to the GenticsImageStore is actually the host name of some front end web server for example. In such constellations, the host the request is made to may not be reachable from the host the GenticsImageStore runs on, and in such cases it is useful to be able to specify a custom urlPrefix which should include the scheme, host and optionally the port of the host where images should be fetched from. For example http://localhost:8080 May be null.

uriMapper

private volatile com.gentics.api.imagestore.ImageUriMapper uriMapper

Will be instantiated with a class given by an optional servlet parameter which enables the user to customize exactly how requests to images are mapped to the actual location where the image will be fetched from. May be null.

requestDecoratorClass

private volatile com.gentics.api.imagestore.RequestDecorator requestDecoratorClass

Will be instantiated with a class given by an optional servlet parameter which enables the user to modify header information and data in requests to the GenticsImageStore May be null.

secret

private volatile String secret

Configured secret for resize validation

Constructor Detail

GenticsImageStoreServlet

public GenticsImageStoreServlet()

Method Detail

init

public void init()
          throws javax.servlet.ServletException

Overrides:

init in class javax.servlet.GenericServlet

Throws:

javax.servlet.ServletException

doPost

protected void doPost(javax.servlet.http.HttpServletRequest request,
                      javax.servlet.http.HttpServletResponse response)
               throws javax.servlet.ServletException,
                      IOException

Overrides:

doPost in class javax.servlet.http.HttpServlet

Throws:

javax.servlet.ServletException

IOException

doGet

protected void doGet(javax.servlet.http.HttpServletRequest request,
                     javax.servlet.http.HttpServletResponse response)
              throws javax.servlet.ServletException,
                     IOException

Overrides:

doGet in class javax.servlet.http.HttpServlet

Throws:

javax.servlet.ServletException

IOException

toImageUri

private URI toImageUri(javax.servlet.http.HttpServletRequest request,
                       String imagePath)
                throws javax.servlet.ServletException

Gets the absolute URI for a relative image path. If the urlPrefix servlet parameter is provided, it will be used to make the given imagePath absolute. If urlPrefix is not provided, the scheme, host and port of the given request will be used to make the given imagePath absolute. Additionally, if the urlMapper servlet parameter is provided, it will be given the now absolute imagePath and whatever it returns replaces the absoulte imagePath.

Parameters:

request - The request to this servlet which fetches the image from the path specified with imagePath.

imagePath - The relative path to an image.

Returns:

The absolute URI for this image.

Throws:

javax.servlet.ServletException - If the given imagePath can not be made absolute because it is of an incorrect format.

doResizing

protected void doResizing(String mode,
                          String width,
                          String height,
                          boolean cropandresize,
                          String topleftx,
                          String toplefty,
                          String cropwidth,
                          String cropheight,
                          javax.servlet.http.HttpServletRequest request,
                          javax.servlet.http.HttpServletResponse response,
                          String imagePath)
                   throws javax.servlet.ServletException,
                          IOException

Do the resizing of an image and return the image

Parameters:

mode - resizing mode

width - new width

height - new height

request - servlet request

response - servlet response

Throws:

javax.servlet.ServletException

IOException

writeImageToResponse

protected void writeImageToResponse(com.gentics.api.lib.upload.FileInformation image,
                                    javax.servlet.http.HttpServletResponse response)
                             throws IOException

Write the image into the servlet response

Parameters:

image - image data

response - servlet response

Throws:

IOException
